SFP28 25G WDM Series
Features
Operating Data Rate up to 25.78Gbps
operating case temperature Standard: 0℃~+70℃ Extended: -20℃~+85℃ Industrial: -40℃~+85℃
SFP28 package with duplex LC receptacle connector
Hot-pluggable capability
Single 3.3V power supply
CWDM/MWDM/LWDM DFB transmitter and high performance PIN receiver
Up to 10km transmission distance over SMF
Low EMI and excellent ESD protection
Built- in Digital Diagnostic Monitoring (DDM) function
Class I laser safety standard IEC-60825 compliant
RoHS2.0 compliance
Applications
25GBASE
25Gbps Fiber Channel
5G eCPRI application
General The Gigac 25Gbps SFP28 module GWCP-XXEE-10 transceivers supports 25G CPRI and Ethernet application, it is offered in a cost-effective SFP28 form factor and I2C interface. The module supports a link length up to 10km on standard single mode fiber such as SMF-28.The module converts 25Gbps electrical data to DFB-based high-performance optical signals for optical transmission. Reversely on the receiver side, the module converts 25Gbps optical signal to electrical data with PINTIA based receiver and CDR IC chip. And also the module Compliant with CMCC Open WDM technical requirements.
Order Information
Table 1-Order Information
Note: 1. Case Temperature
Note: 2. Part Number "XX" indicates that the wavelength form is determined,See Table-6.1,For example 1270nm wavelength product Number GWCP-27EE-10.
Note: 3. Part Number "XX" indicates that the wavelength form is determined,See Table-6.2,For example 1267.5nm wavelength product Number GWCP-M1EE-10.
Note: 4. Part Number "XX" indicates that the wavelength form is determined,See Table-6.3,For example 1269.23nm wavelength product Number GWCP-L1EE-10.
——————————————————————————————————————
